AGR-TR
AGR-TR
PRODUCT DESCRIPTION
1.Rated voltage: 300/500V
2.Operating temperature：-60～+200℃
3.Conductor: solid core or stranded tinned copper wire
4.Insulation：Silicone rubber
5.Widely used in lighting fixtures, household appliances, electric appliances, meters and instruments, motor lead wires and electronics, lamps and lanterns, combustion appliances and other high-temperature environment.
PRODUCT PARAMETERS
|
线规AWG(mm2) |
导体支数/线径Spec(mm) |
绝缘厚度 InsulationThickness (mm) |
平均外径 Avg O.D(mm) |
最大导体电阻Max Cond. resistance（Ω/km ,20ºC） |
包装米/卷 Packing (m/roll) |
电压Voltage (V) |
|
30 |
14/0.07 |
0.45 |
1.30 |
381 |
305 |
300 |
|
28 |
21/0.07 |
0.45 |
1.30 |
239 |
305 |
300 |
|
26 |
32/0.07 |
0.50 |
1.50 |
150 |
305 |
300 |
|
24 |
52/0.07 |
0.50 |
1.60 |
94.20 |
305 |
300 |
|
22 |
84/0.-07 |
0.50 |
1.80 |
59.40 |
305 |
300 |
|
20 |
140/0.07 |
0.50 |
2.10 |
36.70 |
305 |
300 |
|
18 |
210/0.07 |
0.60 |
2.40 |
23.20 |
305 |
600 |
|
18 |
384/0.05 |
0.60 |
2.40 |
23.20 |
305 |
600 |
|
16 |
353/0.07 |
0.76 |
3.06 |
14.60 |
305 |
600 |
|
15 |
427/0.07 |
0.76 |
3.30 |
11.30 |
305 |
600 |
|
14 |
530/0.07 |
0.76 |
3.50 |
8.96 |
305 |
600 |
|
13 |
653/0.07 |
0.76 |
4.00 |
7.10 |
305 |
600 |
|
12 |
855/0.07 |
0.76 |
4.50 |
5.64 |
100 |
600 |
|
11 |
1080/0.07 |
1.14 |
5.50 |
4.48 |
100 |
600 |
|
10 |
1050/0.08 |
1.14 |
6.00 |
3.546 |
100 |
600 |
|
10 |
1368/0.07 |
1.14 |
6.00 |
3.546 |
100 |
600 |
|
8 |
2160/0.07 |
1.52 |
7.20 |
2.23 |
100 |
600 |
|
7 |
2701/0.07 |
1.52 |
8.00 |
1.768 |
100 |
600 |
|
6 |
3420/0.07 |
1.52 |
8.50 |
1.403 |
100 |
600 |
