PRODUCT DESCRIPTION
1.Rated voltage: 500/1000V
2.Operating temperature：-60～+180℃
3.Conductor: solid core or stranded tinned copper wire
4.Insulation：Silicone rubber
5.Widely used in AC rated voltage 690V, 1140V and below F-class, H-class insulation motor and electrical lead wires, widely used in navigation, national defense, train and other high-power motors.
PRODUCT PARAMETERS
|
导体Conductor |
绝缘厚度 Insulation thickness(mm) |
电缆外径 O.D (mm) |
最大导体电阻 |
||||
|
截面积area(mm2) |
结构Strand (No/mm) |
直径 O.D(mm) |
500V |
1000V |
500V |
1000V |
Max Cond. Resistance （Ω/km ,20ºC） |
|
0.5 |
28/0.15 |
0.9 |
1.0 |
1.2 |
2.90 |
3.30 |
40.10 |
|
0.75 |
24/0.20 |
1.15 |
1.0 |
1.2 |
3.20 |
3.60 |
26.70 |
|
1.0 |
32/0.20 |
1.3 |
1.0 |
1.2 |
3.30 |
3.70 |
20.00 |
|
1.5 |
48/0.20 |
1.6 |
1.0 |
1.2 |
3.60 |
4.00 |
13.70 |
|
2.0 |
40/0.25 |
1.85 |
1.0 |
1.2 |
3.90 |
4.30 |
9.90 |
|
2.5 |
49/0.25 |
2.0 |
1.0 |
1.2 |
4.00 |
4.40 |
8.21 |
|
4 |
56/0.30 |
2.8 |
1.2 |
1.4 |
5.20 |
5.60 |
5.09 |
|
6 |
84/0.30 |
3.6 |
1.2 |
1.5 |
6.00 |
6.60 |
3.39 |
|
10 |
84/0.40 |
4.6 |
1.4 |
1.6 |
7.40 |
7.80 |
1.95 |
|
16 |
126/0.40 |
5.8 |
1.4 |
1.6 |
8.60 |
9.00 |
1.24 |
|
25 |
196/0.40 |
7.6 |
1.6 |
1.8 |
10.80 |
11.20 |
0.795 |
|
35 |
494/0.30 |
8.8 |
1.8 |
2.0 |
12.40 |
12.80 |
0.565 |
|
50 |
396/0.40 |
10.6 |
2.0 |
2.2 |
14.60 |
15.00 |
0.393 |
|
70 |
551/0.40 |
12.8 |
2.0 |
2.2 |
16.80 |
17.20 |
0.277 |
|
95 |
760/0.40 |
14.8 |
2.2 |
2.5 |
19.20 |
19.80 |
0.210 |
|
120 |
608/0.50 |
16.5 |
2.2 |
2.5 |
21.00 |
21.50 |
0.164 |
|
150 |
760/0.50 |
18.2 |
2.4 |
2.6 |
23.00 |
23.40 |
0.132 |
|
185 |
925/0.50 |
20.0 |
2.4 |
2.6 |
24.80 |
25.20 |
0.108 |
